OPERATING CONDITIONS
Maxiumum fluid temperature up to +40℃
Maximum sand content :3%
Maximum immersion :50m
Minimum well diameter :4"
OPERATING CONDITIONS
Maxiumum fluid temperature up to +40℃
Maximum sand content :3%
Maximum immersion :50m
Minimum well diameter :4"
1 High quality stainless steel
Carefully selected materials, high-quality stainless steel.
High temperature resistance, corrosion resistance, high toughness
2 All-copper motor, powerful performance
Large all-copper coils for stronger power
3 Stainless steel rotor shaft
Intelligent finishing casting stable operation, reduced wear and a long life.
High precision bearing, long time work stable, guaranteed product.
4 Built-in high toughness rubber cup
Deep water pressure stabilization, increased diving depth and more stable pump operation.
| Components | Material |
| Delivery casing | AISI 304 SS |
| Strainer | AISI 304 SS |
| Motor external casing | AISI 304 SS |
| Top chock | Cast-iron ASTM No.30 |
| Bottom support | AISI 304 SS |
| Mechanical seal | Graphite-Ceramic |
| Shaft | AISI 304 SS - ASTM 5140 |
| Seal lubricant oil | Oil for food machinery and pharmaceutical use |
