OPERATING CONDITIONSM
Maxiumum fluid temperature up to +40℃
Maximum sand content :3%
Maximum immersion: 50m
Minimum well diameter: 2" / 3"
OPERATING CONDITIONSM
Maxiumum fluid temperature up to +40℃
Maximum sand content :3%
Maximum immersion: 50m
Minimum well diameter: 2" / 3"
1 High quality stainless steel
Carefully selected materials, high-quality stainless steel.
High temperature resistance, corrosion resistance, high toughness
2 All-copper motor, powerful performance
Large all-copper coils for stronger power
3 Stainless steel rotor shaft
Intelligent finishing casting stable operation, reduced wear and a long life.
High precision bearing, long time work stable, guaranteed product.
4 Built-in high toughness rubber cup
Deep water pressure stabilization, increased diving depth and more stable pump operation.
| COMPONENTS | MATERIAL |
| Delivery casing | AISI304 SS |
| Strainer | AISI304 SS |
| Motor external casing | AISI304 SS |
| Top chock | Cast-iron ASTM NO.30 |
| Bottom support | AISI304 SS |
| Mechanical seal | Graphite-Ceramic |
| Shaft | AISI304 SS - ASTM5140 |
| Seal lubricant oil | Oil for food machinery and pharmaceutical use |
