OPERATING CONDITIONS
Maximum fluid temperature up to +35℃
Maximum sand content: 0.25%
Minimum well diameter: 5"
OPERATING CONDITIONS
Maximum fluid temperature up to +35℃
Maximum sand content: 0.25%
Minimum well diameter: 5"
1 High quality stainless steel
Carefully selected materials, high-quality stainless steel.
High temperature resistance, corrosion resistance, high toughness.
2 Stainless steel strainer
Effective isolation of debris, filtration more fine service life long.
3 All-copper motor, powerful performance
Large all-copper coils for stronger power.
4 Stainless steel rotor shaft
Intelligent finishing casting stable operation, reduced wear and long life.
High precision bearing, long time work stable, guaranteed product.
5 Built-in high toughness rubber cup
Deep water pressure stabilization, increased diving depth and more stable pump operation.
